Power Supply PFP 700

Power Supply PFP 700

Price: Contact Us
This item is not available for order online
  • Output voltage 24 V DC
  • Output load 14 VA
  • Short-circuit-proof
  • LED indication
  • FM approved

Description

The PFP 700 power supply is used to supply control inputs on the burner control unit or to provide auxiliary power to relay cards.

The operating status is displayed on the front panel (green LED). In the event of an overload at output I > 600 mA the red LED comes on, the green LED goes out and the PFP 700 switches off the output.

Applications

Click on images for close-up view.

Application for Power Supply PFP 700 The operating status is displayed on the front panel (green LED). In the event of an overload at output I > 600 mA the red LED comes on, the green LED goes out and the PFP 700 switches off the output.

Specifications

Power consumption: 25 VA
Output load: 24V DC, 600 mA, short-circuit-proof.
Fine-wire fuse 0.37A, slow blowing, acc. to UL.
Weight: approx. 1.7 lbs (0.75 kg)

Jump to PF-19 Module page
