QUID
TraxBus Infrared Address Programmer
- Infrared interface
- Easily set TraxBus address for QBK devices
- Li-Poly rechargeable battery via USB mini-B port
- USB charger included
Price:
Contact Us to order
Description
QUID makes TraxBus addressing for QBK devices a breeze. An internal lithium polymer battery provides the power supply for QUID.
Use the USB port on the unit, along with the included USB cable and 115..230Vac charger, to charge the battery. The LED is red while charging and green once charging is complete.
Documentation
 |
QUID Technical Sheet |
Procedure
1.Set ZONE and UNIT to be assigned to the QBK device
2. Press the button to put the QBK device in MANUAL SHUTDOWN
3. Point QUID toward the QBK device pushbutton at a distance of 30-60 cm (12-24”)
4. Press the QUID key
If the configuration is successful, the green OK indicator will illuminate. In case of error, the red KO indicator will illuminate.
